Matek's CAN-G474 is a Node adapter based on ArduPilot AP-Periph firmware.
With this board, you will be able to more easily use ArduPilot to convert GNSS, Compass, barometers, airspeed sensor, PWM and buzzer devices to DroneCAN devices.
CAN-G474 has STM32G474 chip and 5Mbit/s transceiver.
Specifications
- Input voltage range: 4.5~5.5V @5V pad/pin
- Power consumption: 62mA
- Operating Temperatures: -30~85 °C
- ST debug, SWC & SWD(on bottom side)
- UART1(TX1,RX1) support firmware update in DFU mode
- 11x PWM outputs
- 1x SPI
- 2x I2C bus
- MCU: STM32G474CE, 512KB Flash
- CAN transceiver data rates up to 5Mbit/s
- 2x CAN bus
- 4x UARTs
LED
- Blue, Fast blinking, Booting
- Blue, Slow blinking, communicating with flight controller
- Red, 3.3V indicator
Included
- 1x CAN-G474 board
- 2x JST-GH-4P to JST-GH-4P 20cm silicon wire
- 1x JST-GH-6P to JST-GH-6P 20cm silicon wire
