Manufacturer : Iflight / Référence : B014032

BLITZ Whoop F7 AIO V1.1 By Iflight

Hors stock
€148.90
Out-of-Stock Notify me when the product is available again

15 points loyalty thanks to this product

Thanks to our loyalty program, you collect 1 point with each 10 euros you spend. The points will be collected in your personal account. 1 loyalty point will count for your voucher as 0.2 euros.

Shipping costs from 49€ pour France
Same day shipping for orders placed before 3:30pm (Monday to Friday)

Related accessories

Related products

Technical characteristics

Version 1.1 of the AIO from the BLITZ series of Iflight.

Compatible with DJI O3 and Vista/Polar systems, this F745 55A AIO consists of a BMI270 gyro, a DPS310 barometer and a 16MB blackbox, among other things.

FC

  • MCU: BGA-STM32F745
  • Gyro: BMI270
  • Blackbox: 16MB Onboard Flash
  • BEC output: 5V 2.5A
  • WS2812 LED Strip: Yes
  • Buzzer: Yes
  • Barometer: DPS310
  • Connector: Micro-USB
  • OSD: IFLIGHT OSD (AT745E）
  • FC Firmware：IFLIGHT_BLITZ_F7_AIO
  • Mounting pattern: 25.5*25.5mm φ3mm
  • Dimensions: 35*35mm
  • Weight: 10.5g
  • BEC: 5V 2A / 3A
  • Input voltage: 2-6S, support LIHV battery
  • Smartaudio / IRC Tramp VTX protocol supported

ESC

  • ESC MCU: BB21
  • Driver: FD6288
  • Input voltage: 2-6S Support LIHV battery
  • Output current: 55A, peak value 65A (10 seconds)
  • ESC firmware: Q-H-40 - Bluejay, 0.16, 24kHz
  • Current sensor: ratio 200 (1/10mV/A)
  • BEC: NO
  • ESC Telemetry: NO
  • Bidirectional DShot: Yes(need to use Bluejay firmware)
  • Supports DShot DShot150/300/600/MultiShot/ OneShot etc.

Included

  • 1x BLITZ F7 AIO
  • 2x Capacitor 470uF/35V
  • 1x XT30U Male 18AWG cable 70mm
  • 1x 1.0-7P cable 50mm-28mm
  • 1x 1.0-7P cable 50mm
  • 4x M2 silicon grommets
  • 8x M2*12mm screws
  • 8x M2 Transparent Nylon Nut
  • 10x 0.8mm black Heat shrink tube 10mm
